7 Tons Kitchen Garbage Truck

Product overview

ZBH5080TCAJXE6 7 tons Kitchen garbage truck is a new generation of kitchen garbage truck products developed by Changsha Zoomlion Environmental Industry Co., Ltd. on the basis of digesting and absorbing the advantages of similar products at home and abroad, combined with its own years of design experience. The vehicle adopts jiangling JX1083TG26 class II automobile chassis modification, which has high operation stability, beautiful appearance and excellent performance. Its comprehensive performance has reached the advanced level of similar domestic products.

Functions overview
7 tons Kitchen garbage truck adopts side bucket feeding, which CAN adapt to standard 240L/120L garbage bin. The filter board structure of garbage bin CAN realize the preliminary solid-liquid separation of kitchen garbage (optional). The product adopts CAN bus control, high degree of automation, one-key automatic unloading function, which greatly reduces the labor intensity of the operator. Two kinds of discharging methods: airtight discharging and pushing discharging can be applied to different users' needs.

Scope of application
7 tons Kitchen garbage truck is mainly used for collecting and transporting food waste produced by restaurants, hotels and canteens.

Main structure and performance characteristics

1、 The back door

The main body of the back door is made of high quality stainless steel welding. In order to ensure the parts of product sealing transportation and discharging, there are two optional configurations of the standard type back door and closed type back door according to customer needs. The bid-winning type can realize pushing and discharging, and the closed type can realize closing and pushing and discharging.
2、 Bin
Dustbin is the product of kitchen waste collection and storage components, but also the back door, shovel, chassis, side bucket mechanism and other important components of the connection matrix, its reasonable structural design to ensure the product performance optimization: side surface design to improve the overall frame stiffness at the same time increase the product beauty; The top rib adopts open structure, not easy to water; The front end of the garbage can is designed with a clean water tank, and the left side is designed with a toolbox to facilitate the cleaning of products and the storage of tools; The bottom of the garbage bin is designed with sewage tank (optional), which can effectively separate the solid and liquid of the kitchen garbage. The bottom plate of the sewage tank adopts the inclined way of front high and back bottom, which can make the sewage discharged completely through the tail sewage outlet without causing part of the sewage to accumulate in the front of the sewage tank. And a special cleaning system, simple and quick; The rear door is equipped with water bars on both sides to further prevent sputtering of sewage when pushing and discharging materials.
3、 Chassis
The chassis is JX1083TG26 no.6 chassis, and the engine is JX4D306H produced by JMC.
4、 Side bucket mechanism

The side bucket mechanism is the part that dumps Chinese food waste into the dustbin. It is driven by the oil cylinder and can realize the feeding and reset of the mechanism through the chain or connecting rod device. Side bucket mechanism can be installed with weighing system according to user requirements to realize garbage weight measurement.
5、 Push the shovel
Push shovel is the product to realize garbage discharge components, driven by the oil cylinder, with the help of wear-resistant nylon slider along the dustbin track sliding; Push the garbage through the discharge port or back door to open the discharge.
6、 Electric control system
CAN bus + controller, through the program to control the operation of the function, high degree of automation, components adopt well-known brands at home and abroad.
7、 The hydraulic system

It is mainly composed of high quality solenoid valve, oil cylinder and pipeline, through the valve to control the oil cylinder to achieve product action, stable control, high efficiency, pipe sleeve pipe, high cleanliness, safe and reliable.
8、 Cleaning system
Cleaning system is composed of water tank, high-quality water pump, water gun and so on. The volume of water tank is leading in the industry. High-quality water gun ensures good use effect.

Operating position

Feeding mechanism operating lever Operation panel

Main technical parameters of the product

Main Advantages
The main components have strong resistance to acid and alkali and other corrosive substances
Main components box body, rear door body, screw machine and water tank are made of 304 stainless steel, acid and alkali corrosion resistance;
Appearance beautiful and generous, solve the problem of water on the top

Box body and rear door arc shape, the whole machine is beautiful and generous; The top rib plate of the box body adopts open plate structure, and the side plate is provided with drainage holes;

Solid-liquid separation (optional), sewage tank has better sewage discharge effect

A large number of filter holes are arranged at the bottom of the bin, which can realize the preliminary separation of solid and liquid of the food waste in the bin; The bottom plate of the sewage tank is inclined with high front and bottom back, so that the sewage can be completely discharged through the tail sewage outlet without causing part of the sewage to accumulate in the front of the sewage tank
The dustbin and the rear door assembly between sealing, automatic discharge action reliability
The dustbin and the rear door assembly are sealed with specially reinforced silica gel strip, with good sealing performance and eliminating secondary pollution; In addition, the rear door and the lock pin are controlled by electrical logic, which ensures the automatic discharge action with higher reliability.

The cleaning system has perfect function and long operation time

The capacity of the cleaning tank is in the leading level in the industry, and the cleaning method of high pressure and small flow can ensure a longer cleaning time. In addition, the sewage tank can be washed by connecting fire water outside the water belt.
6、 Safe and reliable
Equipped with voice alarm system. Can send a variety of voice alarm and prompt information when loading and unloading operations.
Equipped with rear door safety brace. Provides reliable safety protection during maintenance operations.
7、Advanced electronic control system
Difference between PLC or relay control widely used in industry, products on the control mode fully draw lessons from the foreign advanced control technology, adopts CAN bus + special controller, the product a high degree of automation, good reliability, low fault rate and engine speed automatic control effectively save energy, humanized control operation function.
8、Easy operation control
The product feeding is controlled by a handle, and the speed can be changed freely according to the working condition. The two unloading modes can be switched freely, with one-key operation, strong adaptability to different working conditions, simple operation, clear function to distinguish between maintenance mode and working mode, safe and reliable.
9、 Good quality
The key components of electrical and hydraulic systems are international famous brands, such as: proximity switch, operation button, circuit breaker, cylinder seals, etc., improve the reliability of kitchen garbage truck;
10、 Configuration Diversification
Nearly 10 kinds of common configurations of customers can be freely matched. In addition, advanced open program control can further develop product functions to meet the different needs of customers to the maximum extent.

Optional device
