Carriage Removable Garbage Truck Truck

ZBH5251ZXXDFE6 Carriage removable garbage truck truck is independently developed and designed by our company to match the integral garbage compressor and the box body of horizontal separation station (hereinafter referred to as "arm truck").

Send Inquiry

Product Introduction

Product overview
ZBH5251ZXXDFE6 Carriage removable garbage truck truck is independently developed and designed by our company to match the integral garbage compressor and the box body of horizontal separation station (hereinafter referred to as "arm truck"). The car is beautiful in appearance, excellent in performance, easy to operate, the driver can control all actions in the cab. The chassis adopts tianlong DFH1250D4 class II automobile chassis produced by Dongfeng Commercial Vehicle Co., LTD., and the emissions meet the national ⅵ standard. The jib device is made by Shanghai Waller Hoisting Equipment Company or Hunan Wuling Machinery Manufacturing Co., LTD. The truck is a reliable, efficient, easy to operate garbage truck.

Functions overview

The main functions of the arm pulling truck are pulling boxes, unloading boxes, garbage transfer, unloading, etc.

Scope of application
Carriage removable garbage truck truck mainly matches LYSZ15A, LYSZ18A, LYSZ20CY and other integral garbage compressors, XT22 and other boxes.

Main structure and performance characteristics
This puller is mainly composed of chassis, puller device, rear support device, hydraulic system, electrical system, etc., as follows:

1. Chassis
The chassis. Tianlong DFH1250D4 type 2 car chassis modified by Dongfeng Commercial Vehicle Co., LTD. The chassis has strong power and large carrying capacity, and is one of the most advanced and reliable national ⅵ emission commercial vehicle chassis in China.
The engine. Dongfeng Cummins D6.7NS6B290 diesel engine, rated power 213kW, emissions meet the national ⅵ standard.
2. Arm device

The pull arm device is installed on the chassis, and its main functions are pulling boxes, unloading boxes and unloading materials, etc.
The box lock in the arm pulling device is mainly used to lock the box, restrict the movement of the box, ensure safe transportation, and play the role of protecting the arm pulling device in the unloading process.
3. Rear support
The rear support device is mounted at the end of the chassis girder.
When the vehicle is pulling or unloading the dustbin with full load, the outrigger cylinder should be fully extended so that the rear support roller can support the ground to prevent the vehicle from tipping backwards. When the vehicle is running normally, the outrigger cylinder must be retracted and the supporting roller retracted.
4. The hydraulic system
Hydraulic system is the power and control system to realize the functions of the boom car.
The hydraulic system of the boom car is an open system. The oil pump relies on the force retractor to take force and provide pressure oil to the cylinder of each loop. The flow direction of pressure oil is controlled through the multi-way valve, so as to control the work of each loop. The hydraulic system is composed of the main cylinder loop, the slide arm loop, the locking loop, the rear support loop and the compartment loop. The maximum working pressure of the system is 30MPa.

Because the box of the boom car needs to work away from the vehicle, the loop of the car is connected to the hydraulic system of the car through the quick change joint.
5. Electrical system

The electrical system of the boom car is powered from the chassis power supply. Through the control of switches, relays and proximity switches, it mainly realizes the lifting of the main arm, the expansion and expansion of the sliding arm, the switch of the box lock, the retracting and retracting of the rear support and the switch of the box unloading door.
6. Job operation mode
Carriage removable garbage truck truck is electrically controlled. The operator can complete all actions in the cockpit through the control of the control box button.

Operation box. Located on the left side of the driver's seat, mainly used for pulling boxes, unloading boxes and unloading operations.
Power supply box. Located on the right side of the driver's seat, it controls the power supply to the arm puller.
Force grab switch, stop force grab switch. It is located in the front upper part of the cab for controlling the force extractor.

Main technical parameters of the product

Project		Unit	Parameter
The vehicle parameters	Maximum gross mass	kg	25000
	Vehicle readiness quality	kg	11300
	Rated load mass	kg	13570
	Overall dimensions (length × width × height)	mm	8430×2500×3145
	The wheelbase	mm	4350+1350
	Front/rear suspension	mm	1480/1250
	Approach Angle/departure Angle	( °)	20/21
	Minimum ground clearance	mm	240
Job performance	Box pulling operation time	s	≤60
	Unloading operation time	s	≤60
	Discharging cycle operation time	s	≤110
	Tipping point	( °)	50
	Hook height of heart	mm	1570
	External lead-in width	mm	1070
	Horizontal movement distance of the slider	mm	1100
	Rated lifting capacity	t	20
	Load hydraulic system pressure	MPa	30
	Back support mode	/	Rear roller support
Driving performance	Top speed	km/h	89
	Maximum Angle of climb	%	30
	Minimum turning diameter	m	16
The chassis parameters	Chassis model, category and manufacturer	DFH1250D4 Dongfeng Commercial Vehicles Co. LTD DFH1250D4
	Engine model and manufacturer	D6.7NS6B290 Dongfeng Cummins D6.7 NS6B290
	Engine displacement mL	6700
	Fuel consumption L/100Km under limited working conditions	31.3
	The engine is rated at kW	213
	Maximum net power of engine kW	208

Main Advantages
1. Superior performance
High-strength steel is used for the structure of the pull arm, and high-strength investment casting is used for the key parts (as shown in the following four pictures) to improve safety and prolong service life.

2、 Good quality
High accessory configuration. Hydraulic oil pump, main control valve, hydraulic lock, balance valve, proximity switch and other key hydraulic electrical components are internationally renowned brands with excellent quality and high reliability.
3、 Safe and reliable

Electro-hydraulic interlocking logic control. The puller is equipped with multi-layer electro-hydraulic interlocking logic control device for high safety.
In the unloading condition, the box can be lifted and unloaded only after the box lock and self-unloading lock are locked;
Box lock and front frame cannot move during unloading.

Cushioning fallback device. The hydraulic system is set up in the box buffer fall device, when the box falls to a certain Angle, the sensor triggers the electrical signal, the circuit controls the buffer valve in the hydraulic system, so that the box can gently fall to the vehicle, avoid the rigid impact.

The vehicle is equipped with buzzer. The sound alarm will be sounded when the vehicle pull arm coat is operating, which will warn the personnel in the working area and ensure the safety of personal equipment.

Rear support device. The rear roller support device is installed in the rear of the vehicle. Before the arm car pulls the full box, the rear roller is supported on the ground to prevent the vehicle from tipping backwards, which is safe and reliable.

Safety brace. The vehicle is equipped with a safety support device. When the vehicle needs to lift the pull arm for maintenance, the safety brace should be supported to protect the safety of maintenance personnel.

4、 High maintainability

The vehicle is easy to maintain. Vehicle maintenance, can lift the arm, maintenance space is very large; Hydraulic pipes and electrical pipes are arranged in order to facilitate fault finding and component replacement.

Job function
The box. The boom car hooks the box from the ground (or platform) to the car.
Unloading cases. A boom cart lifts the box from the cart to the ground (or platform).
Garbage transfer. The arm carriage carries the box.
Discharge. The trolley lifts the box and dumps the rubbish.

2、 Space required for vehicle operation
(1) The boom truck is equipped with LYSZ18A integrated garbage compressor. When the vehicle is transported and running, the maximum height of the top of the box is 3980mm (the size is for reference only).

(2) The boom truck is equipped with LYSZ18A integrated garbage compressor. When the truck pulls or unloads the container, the maximum height of the top of the container is 5100mm (the size is for reference only).

(3) The boom truck is equipped with LYSZ18A integrated garbage compressor. When the hook just pulls the hanging rod of the box, the length of the car and the box occupies 16,100mm, and the distance between the rear supporting roller and the box is 1500mm (the size is for reference only).

(4) The boom truck is equipped with LYSZ18A integrated garbage compressor. When the vehicle is unloading, the maximum height of the top of the box is 7100mm (the size is for reference only).

Attachment: Size diagram of car and box
