Horizontal Pre-Compacting Garbage Station
It's applicable for large garbage stations with 400 -2000t daily treatment capacity. Featuring high treatment efficiency, high compacted density, and excellent transfer economy, it’s especially suitable for large and super-large garbage stations with ≥1,000t daily treatment capacity and ≥50km transfer distance. System composition: Compactor, loading system, waste transfer vehicle, and auxiliary equipment, including central control system, monitoring system, and exhausting and dedusting system.
Product Introduction
PERFORMANCE FEATURE
-The anti-collapse technology for the pre-compacted waste blocks eliminates the waste spilling after the waste blocks are loaded onto the vehicle to realize excellent in-station environmental-friendliness.
-The sealing technology for the docking between machine and vehicle eliminates the dripping and leakage of sewage and the diffusion of odor and dusts.
-The self-compensation sealing technology for the pushing head almost eliminates the waste inclusion in the rear chamber of pushing head.
-The flexible deflection technology for the compacting cylinder guarantees the balanced force application of the cylinder, protects the seals, and prolong the life.
-The automatic residue removing technology realizes the automatic removing and conveyance of residues in sealed manner after the filtration of percolate, requiring no manual cleaning.
-The 3D dynamic visualized control system real-time dynamically displays and monitors the operation process.
-The intelligent traffic commanding system realizes the full-automatic point-to-point commanding of station vehicles for dumping and container loading at designated positions, requiring no manual intervention.
TECHNICAL PARAMETERS
|
ITEM |
UNIT |
LYSP120 |
LYSP80 |
|
Hourly treatment capacity |
t |
120 |
80 |
|
Daily treatment capacity |
t |
600 |
400 |
|
Compacted density |
kg/m3 |
800-950 |
800-950 |
|
Pump station main power |
kW |
150 |
74 |
|
Model of loading mechanism |
- |
SLT80 |
SLT80/SLT40 |
|
Quantity of effective dumping positions |
Piece |
3 |
3/2 |
|
Gross mass of dumping vehicle |
t |
25 |
25 |
|
Waste tank capacity |
m3 |
45 |
45/33 |
|
Gross mass of transfer vehicle |
t |
49 |
49/31 |
