Sewer Dredging And Suction Truck
It’s suitable for the dredging, cleaning, and suction and clean-up operations of urban sewers, rainwater wells, sedimentation wells, and ditches. It’s also applicable for the cleaning of pipelines and the suction, conveyance, and discharge of wastewater and precipitate in oil refinery, steel, chemical, real estate management, and environmental sanitation industries.
Product Introduction
PERFORMANCE FEATURE
● POWERFUL FUNCTIONS AND EXCELLENT PERFORMANCES (FOR SOME VEHICLE MODELS)
-It incorporates multiple functions for multiple purposes, including dredging, sewage suction, and clean-up.
-The sewage suction hose can be horizontally rotated and vertically luffed and can be telescoped and extended to realize extensive working scope.
-The imported vacuum pump system is combined with Zoomlion’s proprietary technology to realize higher suction capabili- ty than the industry’s average level by 20% and solve the industry’s difficulty of easy air bubble breach into the vacuum system, featuring high suction efficiency and low operating noise.
● HIGH SAFETY AND INTELLIGENCE AND EASY OPERATIONS
-The electric and hydraulic operations are applied to ease the operations.
● GUARANTEED QUALITY AND HIGH STABILITY AND RELIABILITY (FOR SOME VEHICLE MODELS)
-The transfer case, vacuum pump, and high pressure water pump are supplied by world’s high quality part manufacturers, featuring excellent performance, reliable quality, and timely services.
-The sewage tank is made of thickened high-strength steel plates and adopts new sealing materials to eliminate dripping and leakage.
TECHNICAL PARAMETERS
| ITEM | UNIT | ZBH5089GQXJXE6 | ZBH5119GQXQLE6 | ZBH5189GQXDFE6 |
|
Chassis configuration n |
- | JMC Kaiyun | Qingling 700P | Dongfeng Tianjin |
|
Wheelbase |
mm | 3360 | 4175 | 5000 |
|
Maximum pressure of water pump |
MPa | 16 | 19 | 18 |
|
Maximum flow of water pump |
L/min | 207 | 212 | 269 |
|
Water tank capacity |
L | 2800 | 3900 | 5500 |
|
High pressure water hose diameter |
mm | DN25 | DN25 | DN25 |
|
High pressure water hose length |
m | 80 | 80 | 80 |
|
Sewage tank capacity |
m³ | - | - | 5.8 |
|
Maximum vacuum pressure |
% | - | - | 90 |
|
Effective suction range |
m | - | - | >4.5 |
The automatically retractable high pressure reel and the hand-held spray gun are provided to clean this vehicle and the working site.
Triangular type spray nozzle with high penetrability, mushroom type spray nozzle, and bomb type spray nozzle.
The equipped ND25 special dredging high resistance, light weight, low friction resistance, and high resistance against scratches.
The combination of electric, manual, and remote controls features easy operations.
